Maximum Range
1,480
Maximum Cruise Speed
202
Maximum Occupants
6
Useful Load
1,559
Takeoff Ground Roll
2,345
Beechcraft
Baron G58
The Baron® G58 is the perfect balance of horsepower combined with peace-of-mind, twin-engine redundancy and security.
With seating for six, large cargo doors and two baggage compartments, the Baron G58 offers great flexibility for both business and pleasure.
Contact a sales rep
Exterior
Where Functionality and Beauty Meet
Avionics
Command the Next Generation
The Baron G58 is powered by the latest technology in integrated cockpit avionics, the Garmin G1000 NXi.
Features
- ADS-B Out and In
- Wireless data base and flight plan loading
- Garmin Electronic Stability and Protection (ESP) and Underspeed Protection (USP)
- Garmin GI 275 Electronic Standby
- Integrated VFR Sectional Charts
- IFR High and Low Charts with Night Mode
- COM frequency decoding
- Vertical Situation Display
- Selectable Visual Approaches
- Guardian Integrated Carbon Monoxide Detector
- Optional Garmin Connext Satellite Iridium
- Optional Surface Watch for runway safety
Specifications
Baron G58 - Competitive Drive
Dimensions
| Length | 29 ft 10 in (9.09 m) |
| Height | 9 ft 9 in (2.97 m) |
| Wingspan | 37 ft 10 in (11.53 m) |
| Wing Area | 199 ft2 (18.51 sq m2) |
Cabin Interior
| Height | 50 in (1.27 m) |
| Width | 42 in (1.07 m) |
| Length | 12 ft 7 in (3.84 m) |
| Maximum Occupants | 6 |
Baggage Capacity
| Weight | 420 lb (190.5 kg) |
| Volume | 28 ft3 (0.79 m3) |
Weights
| Maximum Ramp Weight | 5,524 lb (2,506 kg) |
| Maximum Takeoff Weight | 5,500 lb (2,495 kg) |
| Maximum Landing Weight | 5,400 lb (2,449 kg) |
| Usable Fuel Weight | 1,164 lb (528 kg) |
| Usable Fuel Volume | 194 gal (734 l) |
| Basic Empty Weight | 3,970 lb (1,801 kg) |
| Useful Load | 1,554 lb (705 kg) |
| Maximum Payload | 1,430 lb (649 kg) |
| Full Fuel Payload | 390 lb (177 kg) |
Performance
| Maximum Cruise Speed | 202 ktas (374 km/h) |
| Maximum Range | 1,480 nm (2,741 km) |
| Takeoff Distance | 2,345 ft (715 m) |
| Ground Roll | 1,373 ft (418 m) |
| Landing Distance | 2,490 ft (759 m) |
| Ground Roll | 1,440 ft (439 m) |
| Service Ceiling | 20,688 ft (6,306 m) |
| Maximum Climb Rate | 1,700 fpm (518 mpm) |
| Maximum Limit Speed | 223 kias (413 km/h) |
| Stall Speed | 73 kcas (135 km/h) |
Powerplant
| Manufacturer | Continental Motors |
| Model | IO-550-C |
| Power Output | 300 hp (300 hp) |
| Propeller Manufacturer | McCauley |
| Description | 3 blade metal, constant speed |
EMAIR Aviation Inc. reserves the right to change about the technical information presented in the introductory pages of the Beechcraft vehicles.
