Maximum Range
1,480
Maximum Cruise Speed
202
Maximum Occupants
6
Useful Load
1,554
Takeoff Ground Roll
1,373
Beechcraft
Baron G58
The Baron® G58 is the perfect balance of horsepower combined with peace-of-mind, twin-engine redundancy and security.
With seating for six, large cargo doors and two baggage compartments, the Baron G58 offers great flexibility for both business and pleasure.
Contact a sales rep
Exterior
Where Functionality and Beauty Meet
Avionics
Command the Next Generation
The Baron G58 is powered by the latest technology in integrated cockpit avionics, the Garmin G1000 NXi.
Advanced Display Technology
The Baron G58 is powered by the latest technology in integrated cockpit avionics, the Garmin G1000 NXi. With an improved graphical interface, more powerful hardware, higher resolution displays, added functionality to improve situational awareness, and optional wireless technology, managing the flight deck has never been easier.
New Features and Options
- Standard ADS-B Out and In
- Optional wireless data base and flight plan loading
- Integrated VFR Sectional Charts
- IFR High and Low Charts with Night Mode
- Enhanced HSI features
- COM frequency decoding
- Vertical Situation Display
- Selectable Visual Approaches
- Optional Surface Watch for runway safety
- Enhanced graphics and faster processing
- Improved joystick with smoother panning
- Simplified maintenance
Specifications
Baron G58 - Competitive Drive
Dimensions
| Length | 29 ft 10 in (9.09 m) |
| Height | 9 ft 9 in (2.97 m) |
| Wingspan | 37 ft 10 in (11.53 m) |
| Wing Area | 199 ft2 (18.51 sq m2) |
Cabin Interior
| Height | 50 in (1.27 m) |
| Width | 42 in (1.07 m) |
| Length | 12 ft 7 in (3.84 m) |
| Maximum Occupants | 6 |
Baggage Capacity
| Weight | 420 lb (190.5 kg) |
| Volume | 28 ft3 (0.79 m3) |
Weights
| Maximum Ramp Weight | 5,524 lb (2,506 kg) |
| Maximum Takeoff Weight | 5,500 lb (2,495 kg) |
| Maximum Landing Weight | 5,400 lb (2,449 kg) |
| Usable Fuel Weight | 1,164 lb (528 kg) |
| Usable Fuel Volume | 194 gal (734 l) |
| Basic Empty Weight | 3,970 lb (1,801 kg) |
| Useful Load | 1,554 lb (705 kg) |
| Maximum Payload | 1,430 lb (649 kg) |
| Full Fuel Payload | 390 lb (177 kg) |
Performance
| Maximum Cruise Speed | 202 ktas (374 km/h) |
| Maximum Range | 1,480 nm (2,741 km) |
| Takeoff Distance | 2,345 ft (715 m) |
| Ground Roll | 1,373 ft (418 m) |
| Landing Distance | 2,490 ft (759 m) |
| Ground Roll | 1,440 ft (439 m) |
| Service Ceiling | 20,688 ft (6,306 m) |
| Maximum Climb Rate | 1,700 fpm (518 mpm) |
| Maximum Limit Speed | 223 kias (413 km/h) |
| Stall Speed | 73 kcas (135 km/h) |
Powerplant
| Manufacturer | Continental Motors |
| Model | IO-550-C |
| Power Output | 300 hp (300 hp) |
| Propeller Manufacturer | McCauley |
| Description | 3 blade metal, constant speed |
EMAIR Aviation Inc. reserves the right to change about the technical information presented in the introductory pages of the Beechcraft vehicles.
